Description
[pdf] [/pdf]
| Product Type | Steam Trap |
| Size | 1 1/2″ |
| Connection | NPT |
| Body Material | Cast Iron |
| Operating Pressure | 75 PSIG/125PSIG |
| Allowable Pressure | 75 PSIG 450F |
| Allowable Temperature | 450F 75 PSIG |
| Part No | FT77L-075-16-N |
Description
The FT Series steam traps are designed to operate at pressures up to 75 PSIG, making them well-suited for low-pressure HVAC systems and light industrial process applications. Commonly used in unit heaters, water heaters, pressing machines, heat exchangers, and coils, these float and thermostatic (F&T) traps provide reliable removal of condensate and air. They are also effective for drip applications, such as draining steam mains and supply lines. With superior air-handling capability, FT Series traps are often a more efficient alternative to inverted bucket traps in most process environments. Their dual inlet-outlet H-pattern connection enhances installation flexibility, allowing for easier integration into various system configurations.
Features
Welded stainless steel thermostatic air vent resists shock from water hammer.
In-line repairable all internals are attached to cover.
H-pattern design allows piping from either side of the steam trap there are two inlet ports at top and two outlet ports at bottom.
F&T traps have excellent air handling capability allows air to be discharged rapidly and steam to enter he system quickly during start-up.
