SCB-5-20: Powder Activated Carbon Block Filter 5m 20″

Description

Key Features

• Extruded under high pressure, eliminating the need for overuse of binders, increasing flow and dirt holding capabilities

• Highly porous, lightweight, clean and tight microporous structure effective at reducing chlorine, taste and odour contaminants

• Pre-washed, eliminating carbon fines

• 75% minimum free chlorine reduction ensures the SCB’s superiority over the ECB

• Chlorine Reduction Start – End of Life (%): 95-75

• Total Chlorine Capacity (mg): 22,750

• Typical Life in UK Water: 113,750L

Typical Applications

• Drinking water
• VOC and THM reduction
• RO protection

Specification

• 5 micron

• Carbon Type – Catalytic Activated coconut carbon

• Netting -Polyethelyne

• End-Cap –PolypropyleneDOE (Double Open-Ended)

• Polypropylene Wrap

• Max Operating Temperature –52C

• Max Operating Pressure Differential –2.5 Bar

• Diameter:Regular (2.5″)

• Flow Rate (lpm):7.6

• Performance:Excellent Chlorine – Medium Sediment

• WRAS Approved

SCB Properties

Length ()	Chlorine Reduction (L) @2mg/l*	Chlorine Reduction (L) @0.2mg/l**	Pressure Drop (Bar)	Flow Rate (LPM)
9 3/4″	13,000	113,750	0.3	3.8
20	26,000	227,500	0.3	7.6
9 1/4BB	59,500	520,625	0.4	7.6
20BB	119,000	1,041,250	0.4	15

**Calculated chlorine capacity using 2mg/l free available chlorine at 0.5mg/l breakthrough

**Calculated chlorine capacity using 0.2mg/l free available chlorine at 0.05mg/l breakthrough

– Pleated Brochure
